Scrap Magnet Three Types for Option:
Normal temperature type (DC-220V TD-60%): for lifting normal temperature steel scraps.
High temperature type (DC-220V TD-60%):for lifting high temperature steel scraps or lift steel scraps in high
Temperature suitation. It is specifically designed to lift steel scrap to steelmaking in steelmaking furnaces. This magnet can treat steel scrap at temperatures of 650 degrees Celsius.
High frequency type (DC-220V TD-75%): for lifting normal temperature steel scraps in high frequency use.
It can be operated more efficiently and frequently since the duty cycle is up to 75%.the over-excitation control system (DC350/DC290V/DC-200V) is also available for large size magnet of this kind, in order to quicken the current, increasing speed and to exert stronger lifting capacity.
Features
a. It can conduct reliable work without consuming electric energy itself.
b. It has features of simple power supply, safe operation, moderate cable (hose) stress volume, flexible rolling and good synchronous performance. Cables will not be hurt easily when pulling.
c. It adopts the slip ring carbon brush structure for electrical energy transmitting for continuous and stable power supply
d.A reversible rotary mechanism is set to avoid spring broken due to e. reversal rolling of the reel.
f. It also has features of simple installation, convenient repairing, compact structure and beautiful appearance.
Specification
| Model | Lifting capacity (kg) | ||
| (cold/hot state) | |||
| Steel ball | Steel ingot | turnings | |
| MW5-50L/1 | 1200 | 220/130 | 80/65 |
| MW5-60L/1 | 2000 | 290/170 | 95/80 |
| MW5-70L/1 | 2500 | 380/200 | 120/100 |
| MW5-80L/1 | 3000 | 480/250 | 150/130 |
| MW5-90L/1 | 4500 | 600/400 | 250/200 |
| MW5-110L/1 | 6500 | 1000/800 | 450/400 |
| MW5-120L/1 | 7500 | 1300/1000 | 650/500 |
| MW5-130L/1 | 8500 | 1400/1100 | 700/600 |
| MW5-150L/1 | 11000 | 1900/1500 | 1100/900 |
| MW5-165L/1 | 12500 | 2300/1800 | 1300/1100 |
| MW5-180L/1 | 14500 | 2750/1100 | 1600/1350 |
| MW5-210L/1 | 21000 | 3500/2800 | 2200/1850 |
| MW5-240L/1 | 26000 | 4800/3800 | 2850/2250 |
| MW5-260L/1 | 30000 | 6100/4900 | 3600/3850 |
| MW5-280L/1 | 34000 | 7100/5700 | 4450/3400 |
| MW5-300L/1 | 39000 | 8350/6700 | 5150/4100 |
CASE
Looking for a reliable scrap metal magnet for your crane? Sinoko Crane offers high-quality, used magnets designed for efficient material handling. Whether you're in construction or recycling, these magnets ensure performance and durability. Explore our products now!
32T Steel Coil Handling Crane Project Case
Sinoko Crane with years of experience in crane manufacturing and design, the steel coil handling crane has helped customers reduce costs and improve the efficiency of steel coil transportation.
Learn More Get a Quote
Installation of QZ-Type Grab Bucket Bridge Crane Project Case
The Sinoko QZ-Type Grab Bucket Bridge Crane was specially designed for a Brazilian client as a grab bucket crane, which significantly improved the client's work efficiency and received unanimous praise from the client.
Learn More Get a Quote
Automotive Repair Facility in Russia 5 Ton Workshop Bridge Crane Project Case
The Sinoko crane, a 5-ton bridge crane tailor-made for a Russian customer's auto repair shop, has helped the customer solve the problem of lifting and transportation, improved the customer's work efficiency, and saved the customer's work costs.
Learn More Get a QuoteFAQs
A scrap metal magnet is used to lift and transport metal objects, often in scrap yards or construction sites, providing efficient material handling.
Yes, our magnets are compatible with a variety of cranes, including overhead and mobile cranes, for lifting metal objects.
Yes, the magnets listed are used but carefully inspected and refurbished to ensure optimal performance and durability.
We offer detailed specifications for each product. You can also contact our team for personalized assistance in matching the magnet to your crane model.
Our magnets come in various capacities, depending on the specific model. Check the product page for detailed weight-lifting capabilities.
With proper maintenance, our magnets can last for years. Regular inspection and care ensure continued efficient performance.
