Overview
Wire rope hoists motor:
Hoists motor is a taper type rotor motor with braking, it has bigger torque, so it canbe adapted to moving frequently, the Maximum torque is 2.43times than the rated torque.
Wire rope hoists gear box:
Hoist Gear Box has specially treated gears for high wear resistance. Each Geared Shaft assembly is supported on ball or roller bearings, to ensure smooth, low-frictionoperation.
Wire rope:
Hoisting rope complies with the exporting standards. The leading rope taken by the Drum does not lip sideways when slack. The factor of safety, on the nominal breaking strength of the rope is six.
Wire rope hoists rope drum:
Grooved Drum, seamless pipe of adequate length to be wounded in one layer and to provide proper support for the rope to minimize abrasive wear is provided. Drum Shaft resolves on Ball Bearing for ensuring smooth running.
Wire rope hoists hook:
The hook block is tested to 150% of full load before assembly. The rope sheaves are fully guarded with protective steel casting. All sheaves rotate on ball bearing. The pulley is thickened and dilated than domestic common pulley.
Features
Remote control or pendant control with 36V control circuit.
Magnetic reversing contactors, both mechanically and electrically interlocked.
Forged heat-treated gravity type hook with upper travel limit switch.
Class F or B insulation motor with both running and over current protection.
Multiple disc brake.
All gears are machine cut, case-hardened alloy steel with shock-resistant ductile cores.
Characteristic
It is equiped with compact structure, convenient adjustment, small volumn, light weight, heavy gravity, easy operation etc.
Specification
| Lifting Capacity | 1~80t |
| Lifting Height | 0~60m |
| Working Class | M3, M6 |
| Ambient Temperature | -20~40℃ |
Please kindly tell us your detailed requirement and the working conditions, we can help you to choose the suitable model as your requirement.
1. Lifting capacity
2. Lifting height
3. Work duty
5. Power supply
6. Other requirements.
Welcome your enquire for details!
CASE
Explore a range of crane project cases that showcase our solutions’ adaptability—from precise, space-saving installations to heavy‑duty operations in challenging environments—demonstrating real-world performance, reliability, and engineering excellence.
Automotive Repair Facility in Russia 5 Ton Workshop Bridge Crane Project Case
The Sinoko crane, a 5-ton bridge crane tailor-made for a Russian customer's auto repair shop, has helped the customer solve the problem of lifting and transportation, improved the customer's work efficiency, and saved the customer's work costs.
Learn More Get a Quote
3× 5T European-Style Single-Girder Cranes for Kenyan Sugar Refinery
Sinoko cranes has designed three 5-ton bridge cranes for Kenyan customers, which have solved their problems. Come and contact Sinoko cranes to solve your lifting problems.
Learn More Get a Quote
5T LDA Single Beam Overhead Crane for Ethiopian Textile Factory
Boost your lifting efficiency with our 5T Single Girder Bridge Crane — reliable, durable, and built for performance. Perfect for workshops, warehouses, and industrial handling.
Learn More Get a QuoteFAQs
This electric wire rope hoist aligns with both FEM and DIN European standards, supported by advanced 3D modeling and finite element analysis—resulting in optimized gear mechanisms, gearbox design, and compact overall dimensions.
The hoist accommodates a wide range of lifting capacities—from 1 up to 80 tons—and is capable of achieving lifting heights exceeding 60 meters.
It uses a taper‑type rotor motor with integrated braking, delivering up to 2.43 times the rated torque, and features a gear box with case‑hardened, wear‑resistant gears and high‑quality bearings for low‑friction performance.
The hoist employs wire rope with a safety factor of six, a grooved drum for proper winding, hooks tested to 150 % of full load, fully guarded sheaves, and robust ball-bearing-mounted pulley systems to guarantee safe and consistent performance.
Its European-style, low-headroom structure achieves a highly compact layout that reduces installation space, helping to minimize building height and maximize effective workspace.
The hoist is suitable for lifting between 1 and 80 tons, heights up to 60 meters, and operates under FEM duty classes M3 or M6. It functions reliably within ambient temperatures ranging from –20 °C to +40 °C.
