Traditional Electrical Hoist Single Girder Overhead Crane is LDA type overhead crane, Compared with European designed cranes, LDA type single girder overhead corane is more economical.
* Hoist and crane is controlled separately, and can move together and separately.
* Flat cable or special cable power supply for electric hoist
* Galvanize slide and cable small trolley
* Smoothly moving, overall aestheticsc
* Set electric taxi speed is high, ensure continuing power supply,
* Operation, hoisting, the point start special smoothly,
* Users can choose according to different needs
LDA electric single beam overhead crane is a light and small lifting machine. Its lifting capacity is 1 Ton 2 Ton 3 Ton 5 Ton 10 Ton 15 Ton 20 Ton. The span is 7.5~31.5m, the working level is A3-A5, and the working environment temperature is -25℃~40℃. The hoisting mechanism has single speed CD1 electric hoist and double speed MD1 electric hoist. This product is widely used in factories, warehouses, material yards and other occasions to lift goods.
It is prohibited to use in flammable and explosive corrosive media environment. This product has two operation modes: ground and remote control.
* Good design, strong rigidity, Compared with European designed cranes, LDA is more economical.
* Good stability, convenient in use and strong commonality.
* Steady travelling with speed adjusting function.
* Wide selection of electric hoists.
LDA Single Girder Overhead Crane usually consists of main beam, end beam, electric hoist, H-track, electrical components and control system. Cranes for single girder overhead crane are usually used with single or double speed lifting hoist or low clearance electric hoists, which include different types of single girder crane.
|
Main girder 1. with strong box type and standard camber. 2. there will have reinforcement plate inside the main girder |
 |
Crane end beam 1.uses rectangular tube manufacturing module 2.buffer motor drive 3.with roller bearings and permanent iubrication； |
|
Electric hoist 1. Lifting Goods or materials； 2. Model CD1/MD1； |
 |
Crane hook 1.Material：Carbon steel or alloy steel or custom required material 2.Grade：M /P /S /T /V grade 3.capacity:1-30t |
 |
Remote controller 1. 2/4/6/8/10/12keys for choosing 2. voltage: as required； |
| Capacity | 1t to 20t |
| Working Duty | A3 |
| Max. Lifting Height | 32m |
| Max. Span | 35m |
| Control Method | Pendent Line Control+Radio Remote Control |
| Lifting Speed | 8/1.3 m/min |
| Traveling Speed | 30m/min |
| Power Supply | 380V 50Hz 3Phase or Customized |
| Main Electric Part | Schneider |
