Semi Gantry Crane Suppliers

Semi Gantry Crane Suppliers

* Because semi gantry cranes ride on the ground rather than on overhead runways, they only need one runway structure.
* Sinokocranes's semi gantry crane don't need concrete foundations.
* Our semi gantry crane installation is fast and simple.
* Depending on the environment and application, gantry cranes can sometimes provide the same material handling capabilities as a comparable bridge crane system, but with a significant cost savings.
* Simple and compact structure
* Llight weight
* Steady performance
* Easy maintenance
* Less wastage

Overview:

semi gantry crane manufacturers

BMH model semi gantry crane manufacturers's semi gantry crane is consisted of gantry frame, main beam, legs (two sets), slide sill, lifting mechanism, travelling mechanism, and electric box. Sinokocranes semi gantry crane is widely used in workshop, storage, port and hydroelectric power station and some other outdoor place especially suitable for working in the production and stockpiling of iron and steel, in shipyards, ports, forestry products manufacturing and stocking, marble firms, Locomotive workshop, marble granite goods yard, especially in many areas of manufacturing, stock and transportation. Sinokocranes single leg semi gantry crane is usually equipped with CD1, type and MD1 type hoist and is in medium and light duty.

Features

Safety is the most important issue for semi gantry crane manufacturers. To ensure the safety, the following safety devices are equiped in Sinokocranes.
1.Crane traveling limit switch
2.Weight overload protection device
3.Lifting height limit device
4.Voltage lower protection function
5.Phase sequence protection function
6.Emergency stop function
7.Rain cover for outside hoist, driving units, electrical cubicle.
8.Warning indicator: flashing lights and warning sound.
9.Wireless infra-detector for anti-collusion

Specification

Loading capacity
0-20t
Lifting height
Up to 22 m
Lifting speed
8m/min or customized stepless control
Span
29 m
Lifting mechanism
CD/MD hoist
Working class
A5 or as customer's need
Working temperature
-20 ~ 40 ℃ or as require
Power supply
AC-3Phase-220/230/380/400/415/440V-50/60Hz or as require
Control voltage
DC -36 / 48V
Motor protection class
IP55
Control way
Cabin, wireless remote, pendant push button.
Safety device
Buffer, current overload protection, overload device, power failure protection
Application area
Factory,workshop inside wall and ouside wall, warehouse, locomotive workshop, water power plant, shipping yard, goods yard, logistics, port, logstic, etc.
Painting color
Yellow, red or customized
