Overview:
European 5T Rail Gantry Crane are mainly consists of girder frame, crane travelling device, hoist as the lifting device and electrical parts, bridge adopts box welded structure, high degree of vertical and horizontal rigidity. It has a strong beam and a stable travelling mechanism. It is rely on the bridge frame along the workshop rail direction moves forward-backward, the hoisting mechanism can be hoist type or winch type according to the lifting capacity and working demand. The trolley along the main beam direction moves left-right and the hook lift up-down. The main electric elements adopts the international brands include Schneider, Siemens, ABB.
Features
1. DIN/FEM design
The European 5T Rail Gantry Crane is designed according to DIN/FEM standard with stepless lifting speed and cross travelling speed and long travelling speed.
2. Light weight design
The crane self height is 20%-25% lower than normal overhead crane, the self weight can be 20%-30% lighter, the wheel press can be 15%-20% smaller, the hook limit will be smaller so the working space will bigger. Moreover, the light crane structure can reduce the workshop cost and protect your workshop.
3. Modular design
All the modular components all can assembly and disassembly for good transportation.
Standard modular components can be manufactured with short producing time and steady quality. So that we can short the delivery time.
What’s more, modular design rail gantry crane can will be much easier for maintenance.
4. High security
We have the following protection measures:
Overload with Alarm and Display Screen Showing Loading Capacity., Anti-swing device for ladle lifting, All traveling and lifting have limit switches, Emergency Stop, Loss voltage protection, Grounded protection, Short circuit protection, Overheating Protection, Overspeed Protection, Overcurrent protection, Faulted phase protection
About Us
Sinoko Crane is an innovative designer and professional supplier of Euro-style overhead & gantry cranes, Euro-style hoist, Euro-style crane kits, which are certified by ISO9001: 2008, CE, etc.
Our eternal pursuit is to offer you quality products with most reasonable prices.
Our ideal aim is to establish a "Win-Win Lasting" cooperation with you.
Our mission is to bring commitment and innovation to our customers in an effort to continually exceed their expectations for service, quality and value for money. We strive to build and maintain strong relationships with our staff, customers and communities, based on integrity and respect.
The 5t gantry crane can be divided into many different types, including single girder, double girder, semi-gantry and portable gantry crane 5 ton. If you want to know more about 5T rail gantry crane, kindly send us email.
Specification
Capacity | T | 5 | ||||
Span | m | 18 | 22 | 26 | 30 | 35 |
Lifting height | m | 10 | ||||
Lifting speed | m/min | 0.66/4; 0.8/5; 1.0/6.3; 1.3/8 | ||||
Trolley travelling speed | m/min | 2.0~20; 3.0~30 | ||||
Crane travelling speed | m/min | 3.0~30 | ||||
Max. Wheel load | KN | 67 | 74 | 81 | 89 | 102 |
Rail recommended | Model | 24kg/m | ||||
Total motor power | kw | 10 | ||||
Main dimension (mm) | Span(m) | 18 | 22 | 26 | 30 | 35 |
Crane base distance | B | 5500 | 5000 | |||
Crane width | B0 | 6235 | 5735 | |||
Trolley rail distance | W | 1600 | ||||
Hook left limitation | S1 | 400 | ||||
Hook right limitation | S2 | 800 | ||||
CASE
Explore how the 5T Rail Gantry Crane can streamline your material handling. Ideal for warehouses, construction sites, and ports, this crane offers reliable 5-ton lifting capacity with easy movement along rails. Learn how businesses are optimizing operations with this versatile solution.
40.5T Rail-Mounted Gantry Crane Installation for Port Logistics Efficiency
The RMG gantry crane designed and manufactured by Sinokocrane has effectively solved the problems for the customers and reduced their operational costs.
Learn More Get a Quote
5T Portable Gantry Crane Deployment for Australian Equipment Rental
The portable gantry cranes provided by Sinoko Cranes for the leasing company of Australian customers have significantly increased the number of rentals for the customers and enhanced the revenue of their companies.
Learn More Get a Quote
Installation of 10T European-Style Gantry Crane for Pakistani Client by Sinoko Cranes
Struggling with slow manual gates? Sinoko's European gantry crane slashed Pakistan customer's downtime by 64%! Transform your access efficiency – contact us!
Learn More Get a QuoteFAQs
A 5T Rail Gantry Crane is a lightweight, portable crane mounted on rails, ideal for material handling in construction sites, warehouses, and outdoor environments. It can lift up to 5 tons and provides efficient, reliable operation.
This crane is designed with a strong, durable frame, equipped with electric hoists and precise control systems for easy and safe operation. It’s ideal for lifting loads in both indoor and outdoor settings with minimal setup.
The 5T Rail Gantry Crane is commonly used in warehouses, factories, construction sites, and ports for moving heavy loads such as equipment, containers, and materials across defined tracks.
As the name suggests, this crane is designed to lift up to 5 tons, making it ideal for medium-duty material handling tasks in various industrial and commercial applications.
Unlike traditional cranes, the rail-mounted design offers more stability and precision for material handling across fixed tracks. It is ideal for applications that require moving goods across a set path or rail system.
Regular maintenance includes checking the crane’s rails, hoisting mechanisms, electrical systems, and safety devices. It’s important to lubricate moving parts and conduct routine inspections to ensure reliable performance.
