Overview:
40 ton Gantry Crane consists of four main parts, namely, the bridge structure, the crane traveling mechanism, the trolley and the electric equipment. All movements of the crane are controlled in the operating room.
40 ton gantry cranes are usually double girder construction which helps to improve the efficiency and safety of your production line. In various lifting applications, we provide different types of 40 ton gantry cranes to meet your actual needs. According to the frame structure, it can be divided into A-frame gantry crane and U-frame gantry crane, and according to the operating mechanism, it can be divided into rail-mounted gantry crane and rubber tire gantry crane.
This type of double beam gantry crane has two conductive forms, cable and sliding contact line. When buy this crane, any form will be fine, and also tell us the crane's working environment and power source. Each type is designed for a specific application and work environment, and has its own advantages and disadvantages. We can design cost-effective lifting solutions according to your requirements to maximize your benefits.
Features
1. 14 months warranty when products leave the factory, or 12 months warranty after installation and commissioning in addition to the human damage factors.
2. 2 years spare-parts provided for better maintenance.
3. Professional technical staffs provide installation, commissioning and training services.
4. Delivery with English user manual, parts manual, product certification and other relevant certificates.
5. Technical advisory for any time.
Specification
Lifting Capacity | T | 16/3.2 | 20/5.0 | 32/8.0 | 50/10.0 | 75/20.0 | ||
Span | M | 18-35 | ||||||
Max. Lifting Height | Main hook | M | 10/12 | |||||
Aux hook | 10.6-12.6 | 10.6-12.6 | 10.7-12.7 | 11.1-13.1 | 11.1-13.1 | |||
Working System | A5 | |||||||
Speed | Hoisting | Main | m/min | 15.3 | 15 | 13.2 | 5.9 | 6.25 |
Aux | 22 | 19 | 17 | 13.2 | 9.28 | |||
Trolley Travelling | 44.7 | 44.7 | 38.6 | 36 | 38.9 | |||
Crane Travelling | 30-35 | 34.5-32.9 | 52.53 | 45-38.6 | 38.5-32.6 | |||
Weight | Trolley | t | 7.1 | 8.1 | 11.7 | 16.8 | 29.4 | |
Total Weight | 92-142 | 105-148 | 92-142 | 111-156 | 189-245 | |||
Max. Wheel Load | 275-369 | 341-435 | 275-369 | 392-483 | 314-361 | |||
CASE
Experience enhanced safety and precision with the Radio-Control 40-Ton Gantry Crane. Perfect for heavy-duty operations, this crane offers seamless control, ideal for large-scale construction, warehouse, and manufacturing tasks. Discover its real-world efficiency.
40.5T Rail-Mounted Gantry Crane Installation for Port Logistics Efficiency
The RMG gantry crane designed and manufactured by Sinokocrane has effectively solved the problems for the customers and reduced their operational costs.
Learn More Get a Quote
5T Portable Gantry Crane Deployment for Australian Equipment Rental
The portable gantry cranes provided by Sinoko Cranes for the leasing company of Australian customers have significantly increased the number of rentals for the customers and enhanced the revenue of their companies.
Learn More Get a Quote
Installation of 10T European-Style Gantry Crane for Pakistani Client by Sinoko Cranes
Struggling with slow manual gates? Sinoko's European gantry crane slashed Pakistan customer's downtime by 64%! Transform your access efficiency – contact us!
Learn More Get a QuoteFAQs
The crane has a lifting capacity of 40 tons, making it suitable for heavy-duty applications in construction, warehouses, and industrial environments where large loads need to be moved safely and efficiently.
Radio control offers operators the flexibility to control the crane remotely, enhancing safety by keeping them away from potential hazards and improving precision in lifting and movement during operations.
Yes, this gantry crane is designed for both indoor and outdoor use, built to withstand tough weather conditions for outdoor operations like heavy material handling in industrial yards or construction sites.
The lifting speed varies, but it is designed for efficient operations with a lifting speed of up to 5 meters per minute and hoist and travel speeds optimized for different job site needs.
This crane is ideal for industries such as construction, steel manufacturing, shipyards, and logistics, where safe, precise, and efficient lifting of heavy materials is required in tight spaces or large outdoor sites.
Yes, Sinoko offers customization options, including different lifting heights, spans, and hoisting mechanisms, to meet the specific requirements of your work environment and operational needs.
