I. Overview of Hydraulic Grab Scrap Handling Crane for Steel Scrap Yard
This is a double girder type gantry crane for outdoor scrap yard use. In many steel plants, the raw material are steel scrap such as HMS and LMS. These raw material need to be processed to be more regular size or shape before being charged into furnace. So this type of gantry crane is used for scrap handling in the scrap yard.
The hydraulic grab is specialized in handling Block or irregular shape of bulk materials, coke, pig iron, steel scrap, slag and so on. Especially popular for loading and unloading bulk materials for train. This type hydraulic grab is widely applicate for Wharf, steel plant. Design for working with tower crane, loading and unloading crane and all kinds industry cranes.
Routine grab bucket volume: 2.0 m 3 ~4.0m 3
Motor Power: 28 kW~45 kW
II. Features of Hydraulic Grab Scrap Handling Crane for Steel Scrap Yard:
Mechanical | No. | Electrical | |
1 | Limit Switch | 1 | Short-circuit protection |
2 | Interlock protection device | 2 | Uner-voltage protection |
3 | Buffer | 3 | Zero protection |
4 | Rail tongs, Anchor device | 4 | Motor overhead protection |
5 | Rail clear plate | 5 | Emergency stop system |
6 | Protective cover | 6 | Current overhead protection |
7 | Bus bar preventer plate | 7 | Security chain protection |
8 | Anti-collision device | 8 | Ground protection |
III. Specification of Hydraulic Grab Scrap Handling Crane for Steel Scrap Yard
Lifting Capacity (T) | 5T | 10T | 16T | 20T | ||
Max Lifting Height (M) | 20T | 18T | 22T | 26T | ||
Span(M) | 10.5-31.5 | |||||
Working System | A8 | |||||
Speed (M/Min) | Trolley | Hoisting | 40.1 | 40.7 | 41.8 | 48.6 |
Travelling | 44.6 | 45.7 | 43.2 | 43.2 | ||
Bridge travelling | 93.7-114.4 | 112.5-101 | 98-87.3 | 87.3 | ||
Weight (T) | Trolley | 5.2/5.9 | 8.2/9.1 | 14.8/15.9 | 19.3/20.4 | |
Total | Indoor | 19.9-41.3 | 26.5-50.4 | 47.3-67.9 | 56.1-75.6 | |
Outdoor | 20.7-42.1 | 27.4-51.2 | 48.5-69 | 57.3-76.8 | ||
Grab | Volume (CUM) | 2.5-0.75 | 5-1.5 | 8-2.5 | 10--3 | |
Dead weight (KG) | 2632-2546 | 4800-4793 | 7841-8305 | 9812-10123 | ||
Rail recommended | 43kg/m, QU70 | |||||
Power Source | 3Phase AC 380V 50HZ (As your demand) | |||||
CASE
Discover how the Hydraulic Grab Steel Scrap Gantry Crane enhances steel scrap handling in yards. Designed for heavy-duty operations, it efficiently lifts and transports scrap metal, improving productivity and safety in steel mills and recycling facilities.
40.5T Rail-Mounted Gantry Crane Installation for Port Logistics Efficiency
The RMG gantry crane designed and manufactured by Sinokocrane has effectively solved the problems for the customers and reduced their operational costs.
Learn More Get a Quote
5T Portable Gantry Crane Deployment for Australian Equipment Rental
The portable gantry cranes provided by Sinoko Cranes for the leasing company of Australian customers have significantly increased the number of rentals for the customers and enhanced the revenue of their companies.
Learn More Get a Quote
Installation of 10T European-Style Gantry Crane for Pakistani Client by Sinoko Cranes
Struggling with slow manual gates? Sinoko's European gantry crane slashed Pakistan customer's downtime by 64%! Transform your access efficiency – contact us!
Learn More Get a QuoteFAQs
This crane is specifically designed for lifting and transporting steel scrap in yards and recycling facilities. It uses a hydraulic grab to efficiently collect and move scrap metal, enhancing productivity in steel processing operations.
The crane is capable of handling heavy loads, with lifting capacities typically ranging from 10 tons to 100 tons, depending on the specific model and customization for scrap handling tasks.
The hydraulic grab allows for precise and powerful handling of steel scrap, ensuring smooth collection, lifting, and transport, even for irregularly shaped or heavy scrap metal pieces, increasing overall operational efficiency.
Yes, the crane can be customized in terms of lifting height, span, grab size, and control systems to suit the specific needs of your steel scrap yard or recycling facility, ensuring optimal performance for your operations.
The crane is equipped with overload protection, emergency stop systems, and advanced safety sensors to prevent accidents and ensure safe lifting and transportation of steel scrap, even in challenging environments.
Regular maintenance includes inspecting the hydraulic system, checking the grab mechanism, and ensuring all safety features and electrical systems are in good condition to ensure reliable and safe operation.
