The JM-Type Slow-Speed Electric Winch is a gear-driven winch built for heavy-duty, low-speed lifting, pulling, and towing. It's perfect for tasks that need short lifting distances and high precision. This winch is commonly used in construction, bridge and dock work, ship anchoring, mooring, and installation of large machinery or concrete and steel structures. Thanks to its strong design, dependable performance, and safety features, it’s a trusted choice in demanding environments.
JM-Type Slow-Speed Electric Winch Feature
1. Slow speed,
2. Steadily working4. High strength component, Durable and Reliable
JM-Type Slow-Speed Electric Winch Specification
Basic Parameter Type | Rated Load ( KN) | Rated Speed (M/MIN) | Rope Capacity (M) | Rope Diameter (MM) | Motor Power (KW) |
| JM1 | 10 | 15 | 100 | 9.3 | 3 |
| JM2 | 20 | 16 | 150 | 13 | 7.5 |
| JM3.2 | 32 | 9.5 | 150 | 15.5 | 7.5 |
| JM5 | 50 | 10 | 270 | 21.5 | 11 |
| JM6 | 60 | 9.5 | 270 | 24 | 15 |
| JM8 | 80 | 8 | 250 | 26 | 15 |
| JM10 | 100 | 8 | 170 | 30 | 22 |
| JM16 | 160 | 10 | 500 | 37 | 37 |
| JM20 | 200 | 10 | 600 | 43 | 45 |
| JM25 | 250 | 9 | 700 | 48 | 55 |
| JM32 | 320 | 9 | 700 | 56 | 75 |
| JM50 | 500 | 9 | 800 | 65 | 90 |
| JM65 | 650 | 10.5 | 3600 | 64 | 160 |
FAQs
The JM-type slow-speed winch is engineered for precision-heavy lifting and pulling at controlled speeds—typically between 5 to 20 m/min. This ensures smooth, stable handling, particularly suited for demanding environments like construction sites, mining zones, shipyards, and factory installations. The gear-reducer drive not only provides reliable torque but also minimizes noise and wear, making it durable and easy to operate.
* Required load capacity and rope length * Desired lifting or pulling speed (slow vs. fast) * Specific job environment and duty cycle * Smaller jobs might suit a compact JM 1 t or 5 t winch; heavy industrial tasks may demand higher-capacity models with longer rope drums.
Absolutely. You can tailor the load capacity, rope length, speed (single or dual), drum size, and voltage configuration to suit precise project needs. Variable frequency drive (VFD) options also allow for adjustable speed and smoother operation.
