Project Overview
In 2025, we successfully delivered 5-ton European single girder overhead crane core components with a matching permanent magnet lifter to a steel structure manufacturing plant in Argentina.
This project demonstrates the advantages of flexible supply chain models in overseas markets, where customers only need to purchase core components while the main beam can be manufactured locally, significantly reducing logistics costs and customs clearance complexity.
Key Specifications at a Glance
| Parameter | Specification |
Project Location | Argentina |
Industry | Steel Structure Manufacturing |
Customer Type | Factory / Industrial Facility |
Crane Capacity | 5 tons |
Magnet Lifter Capacity | 1,000 kg (1 ton) |
Crane Span | 16 meters |
Lifting Height | 8 meters |
Quantity | 1 complete set |
Completion Date | 2025 |
Product Details
1. European Single Girder Overhead Crane Core Components
The project supplied five essential core components of a European-style single girder
overhead crane, excluding the main girder which was manufactured locally by the customer to reduce transportation costs and lead time.
Core Components Supplied:
Electric Hoist: 5-ton capacity with precision lifting control
End Carriages: Complete with motorized travel mechanisms
Control System: Advanced pendant control with emergency stop functionality
Electrical Components: Complete wiring system with connection points
Safety Features: Limit switches, overload protection, and braking systems
2. Permanent Magnet Lifter (1 Ton Capacity)
A high-performance permanent magnet lifting system designed specifically for steel plate and ferrous material handling.
Magnet Lifter Features:
Rated Lifting Capacity: 1,000 kg (1 ton)
Magnetic Technology: Advanced permanent magnet design with no power requirement during lifting
Safety Factor: Minimum 3:1 safety factor for secure lifting operations
Operation: Simple lever-actuated magnetic engagement/disengagement
Application: Ideal for lifting steel plates, bars, and structural components
Technical Specifications
Crane Technical Parameters
Capacity: 5,000 kg (5 tons)
Lifting Mechanism: Electric wire rope hoist
Lifting Speed: 8/0.8 m/min (dual speed)
Cross Travel Speed: 20/2 m/min (dual speed)
Long Travel Speed: 40/4 m/min (dual speed)
Working Class: ISO A5 (Medium duty)
Power Supply: 380V/50Hz/3Ph
Control Method: Pendant push button station
Maximum Wheel Load: Designed per FEM standards
Magnet Lifter Technical Parameter
Rated Capacity: 1,000 kg
Material Compatibility: Carbon steel, low-alloy steel
Minimum Thickness: 5mm (varies by material grade)
Safety Factor: 3:1
Operating Temperature: -40°C to +80°C
Magnet Type: Permanent rare-earth magnet
Activation: Manual lever system
Application Scenarios
Steel Structure Production
Steel Plate Handling: Efficient lifting and positioning of steel plates for cutting and welding operations
Component Assembly: Moving prefabricated steel components during assembly processes
Material Transfer: Transferring materials between workstations and storage areas
Industrial Warehouse Operations
Inventory Management: Organizing and stacking steel products in warehouse storage
Loading/Unloading: Assisting in the loading and unloading of steel materials from vehicles
Space Optimization: Enabling vertical storage solutions through safe overhead lifting
Special Requirements & Solutions
1. Core Components Supply Strategy
Requirement: Supply only core components; main girder to be manufactured locally
Solution Provided:
Provided detailed technical drawings and specifications for local main girder fabrication
Supplied all critical mechanical and electrical components requiring precision manufacturing
Offered remote technical support for local assembly and installation
Ensured compatibility between locally manufactured main girder and supplied components
Benefits:
Reduced overall project cost by eliminating large main girder shipping expenses
Shortened delivery timeline through local fabrication
Supported local manufacturing capabilities
Maintained European quality standards for critical components
2. P22 Rail System with Complete Accessories
Requirement: Matched P22 rail system with full accessory package
Solution Provided:
Technical Compliance:
Rail material符合DIN 536 or ASTM standards
Designed for 5-ton wheel load capacity
Included installation guidelines and torque specifications
3. 50A Seamless Busbar System
Requirement: Matched 50A seamless busbar with complete accessories
Solution Provided:
System Features:
Seamless design for smooth current collection
Copper or aluminum conductor options
IP54 protection rating for industrial environments
Easy installation and maintenance
4. Permanent Magnet Product Customs & Transportation
Requirement: Compliant customs clearance and transportation guarantee
Solution Provided:
Regulatory Compliance:
Properly classified according to HS Code for magnetic lifting devices
Complete IATA/IMDG compliance documentation for air/sea freight
Magnet safety packaging meeting international standards
Material safety data sheets (MSDS) provided
Transportation Security:
Specialized wooden packaging with magnetic field shielding
Clearly marked and labeled packaging per dangerous goods regulations
Insurance coverage for magnetic products during transit
Professional freight forwarder experienced in magnetic materials
Customs Documentation:
Commercial invoice with detailed product descriptions
Packing list with weight and dimensions
Certificate of origin
Test certificates for magnet lifting capacity
Safety operation manuals in Spanish
Quality Assurance & Support
Standards & Testing: Components comply with FEM, ISO, and IEC standards. Equipment is load-tested; magnet lifter is third-party certified.
Full Support: We provide remote support, spare parts, and detailed guides. All parts have a full warranty. Spanish training and documentation are included. We ensure reliable, long-term operation with certified products and local support.
Project Benefits Summary
For the Customer
✓ Cost Effective: Local main girder manufacturing reduced overall project cost
✓ Quick Delivery: Core components shipped promptly; local fabrication reduced lead time
✓ Quality Assured: European-quality components ensure reliable long-term operation
✓ Customized Solution: Tailored to specific steel structure manufacturing needs
✓ Comprehensive Support: End-to-end support from quotation to after-sales service
✓ Safety Compliant: Meeting all relevant safety and regulatory requirements
✓ Efficient Operation: Magnet lifter significantly improves material handling efficiency
Conclusion
This Argentina 5-ton European
single girder overhead crane core components and permanent magnet lifter project demonstrates a successful customized solution that balances cost efficiency with quality and reliability. By supplying core European-quality components while enabling local main girder fabrication, we provided an optimal solution that met the customer's technical requirements, budget considerations, and timeline needs.
The integrated 1-ton permanent magnet lifter further enhanced the material handling capabilities, specifically addressing the steel structure manufacturing industry's needs for safe and efficient steel plate handling. The complete solution, including P22 rail and 50A busbar systems, ensured a turnkey material handling system ready for immediate deployment in the customer's industrial facility.
