Project Overview
Industry: Tobacco Industry Manufacturing
Location: Saudi Arabia
Completion Date: 2025
Customer Type: Manufacturing Factory
Application: Tobacco Workshop Material Handling
Customer Challenge
A leading Saudi Arabian tobacco machinery manufacturer specializing in automated machinery for cigarette production, packaging, filter tubes, and other tobacco products (OTP) required a comprehensive material handling solution for their expanded production facility.
This was a repeat customer who had previously purchased eight jib cranes from Sinokocranes, demonstrating their trust in our quality and service. For this expansion project, they needed:
Multiple crane types for different production areas
High reliability for continuous tobacco processing operations
Flexible solutions for various lifting applications
Professional support for a complex multi-product installation
Our Solution
Sinokocranes delivered a comprehensive crane package tailored to the tobacco industry's strict requirements:
Product Package:
1. Column Jib Cranes (3T-4.1-7) - 2 Sets
| Capacity | 3 tons |
| Lifting Height | 4.1m |
| Total Height | 5.5m |
| Arm Length | 7m |
| Rotation | 270° variable frequency rotation |
| Control | Wireless remote control + hand pendant |
| Work Class | M3 |
| Voltage | 380V 60Hz, 3P |
2. Steel Structure Frame Gantry Crane (3T-3.1-5) - 1 Set
| Capacity | 3 tons |
| Lifting Height | 3.1m |
| Total Height | 4.5m |
| Span | 5m |
| Travel | Electric double speed |
| Control | Wireless remote control + hand pendant |
| Work Class | M3 |
| Voltage | 380V 60Hz, 3P |
3. Low Headroom Electric Chain Hoists - 3 Sets
| Model | SDHL-3T series |
| Running Type | Low headroom design |
| Hoist Body | Double speed, variable frequency double speed |
| Chain | 6mm high-strength chain |
| Voltage | 380V 60Hz, 3P |
| Lifting Heights | 4.1m (2 sets), 3.1m (1 set) |
| Control | Wireless remote control included |
4. Electric No-rail Portable Gantry Crane - Motor-driven
| Capacity | 4 tons |
| Lifting Height | 2m |
| Travel Speed | 6/4 m/min (double speed) |
| Lifting Speed | 0.67/11 m/min |
| Wheels | KM200×300mm rubber wheels |
| Running Motor | 0.75×2 kW |
| Hoisting Motor | 1.2/3.5 kW |
| Control | Infinite variable speed, wireless remote control |
| Protection Class | IP54 |
| Total Weight | Approx. 800kg |
| Power Supply | 3P, 380V, 50Hz |
| Work Class | A3 |
Why They Chose Sinokocranes Again
Proven Track Record with Repeat Customers
This project demonstrates Sinokocranes' strength in building long-term customer relationships:
✅ First Collaboration Success: The client initially purchased eight jib cranes, establishing trust in our quality and service
✅ High Repeat Purchase Rate: This follow-up order for multiple crane types proves our commitment to customer satisfaction
✅ Comprehensive Solution: From column jib cranes to portable gantry cranes, we provided a complete material handling ecosystem
✅ Industry Expertise: Deep understanding of tobacco industry requirements and standards
Pre-Shipment Testing & Quality Assurance
At Sinokocranes, every piece of equipment undergoes rigorous testing before delivery:
Testing procedures included:
Full load testing for all cranes at rated capacity
Operational testing of variable frequency control systems
Wireless remote control range and functionality tests
Safety limit switches and emergency stop verification
Travel mechanism performance testing
Electrical system comprehensive inspection
Tobacco Industry Expertise
Sinokocranes understands the unique requirements of tobacco manufacturing:
Strict Hygiene Standards: Equipment designed for easy cleaning and maintenance
Reliable Performance: Continuous operation capability for 24/7 production schedules
Precise Positioning: Essential for delicate tobacco product handling
Safety First: Advanced safety features for operator and product protection
