Light Type Double Girder Gantry Crane

Light Type Double Girder Gantry Crane

MHS electric hoist double girder gantry crane is the crane with the cantilever, equipped with the CD

Overview:

MHS electric hoist double girder gantry crane is the crane with the cantilever, equipped with the CD, MD style electric hoist. The main beam is box welded structure, and the crane cart running mechanism is driven by 3 in 1 device. Its simple structure, convenient installation, use and maintenance makes it mostly use in the factory, , storehouse, wharf, hydropower station, etc the place that low frequency using or fewer rated weight lifting.
Application Parameters:
1. Suitable for lifting weight: 3~32 ton
2. Span: 10~35 meters
3. Working environment: -25℃~+40℃

Features

1. Overload protection device
2. Top quality long time bearing polyurethane materials buffer
3. Crane traveling limit switch
4. Voltage lower protection function
5. Emergency stop system
6. Lifting height limit device

Specification



Capacity
T
3
5
10
16
20
Span
m
12,16,20,24,30
Operational method

Pendent Line With Press Button /Cabin/ Remote
Speed
Lifting

m/min
8 ,8/0.8
8,8/0.8
7,7/0.7
3.5
3.5
Cross travelling
20
20
20
20
20
Long travelling
Ground
20
20
20
20
20
Cabin
20, 30,45
20, 30,40
30,40
30,40
30,40
Motor
Lifting
Type /kw
ZD41-4/4.5
ZDS1-4/0.4/4.5
ZD141-4/7.5 ZDS10.8/4.5
ZD151-4/13 ZDS11.5/4.5
ZD151-4/13
ZD152-4/18
Cross travelling
ZDY12-4/0.4
ZDY121-4/0.8
ZDY21-4/0.8×2
ZDY121-4/0.8×2
YZD-4/0.8×4
Long travelling
Ground
ZDY21-4/0.8×2
ZDY21-4/1.5×2
YZY22-4/1.5×2
YZR132M2-6/3.7×2
YZR22-4/1.5×2
YZR160M1-6/6.3×2
YZR160M2-6/8.5×2
YZR160M1-6/6.3×2
YZR160M2-6/8.5×2
Cabin
ZDR100-4/1.5×2
ZDR112-4/2.1×2
YZR112L1-4/2.1×2
YZR160M1-6/2.1×2
YZR112L1-4/2.1×2
YZR160M2
YZR160M2-6/8.5×2
YZR160L2-6/11×2
YZR160M2-6/8.5×2
YZR160L2-6/11×2
Electric hoist
Model
CD1/MD1
CD1/MD1
CD1/MD1
CD1
HC
Lifting height
m
6,9,12,15
Working duty

A3
Power supply

380V 50HZ 3phase AC (According to your demand )
