Light Type Double Girder Overhead Crane

Light Type Double Girder Overhead Crane

The light model electric Hoist Overhead Crane has such features as tight dimensions, low building headroom, light dead weight and light wheel load.

Overview:

The light model electric Hoist Overhead Crane has such features as tight dimensions, low building headroom, light dead weight and light wheel load. They are applicable to the transfer, assembly, check and repair as well as load and unload at mechanic processing workshop ,subsidiary workshop of metallurgical mills, warehouse, good yard and power station .They can also be used instead of common double-girder overhead crane at production workshop in light textiles or food industry. It has two kinds of classification ,that is ,light and medium. The working ambient temperature is generally -25℃~40℃.It is forbidden to work in environment with combustible, explosive or corrosive media.

Features

1.Overload warning and limiter
2.Lifting height limit device
3.Voltage lower protection function
4.Phase sequence protection function
5.Emergency stop function
6.Hooks with latch
7.Rubber buffers
8.Laser anti-collision system

Specification



Lifting Catacity
t
5
10/3
16/5
20/5
32/10
Span
m
7.5-22.5
Lifting Height
m
6, 9, 12, 18, 24, 30
Working Class

A3-A4
Electric Hoist

CD/MD
CD/MD
CD/MD
HC
HC
Speed
Main hook
m/min
8(0.8/8)
7(0.7/7)
3.5(0.35/3.5)
3.3
3(0.3/3)
Auxiliary

8(0.8/8)
8(0.8/8)
8(0.8/8)
7(0.7/7)
Trolley Travelling
20
20
20
20
20
Crane Travelling
30
30
30
30
30
Steel Track Recommend

38kg/m
38kg/m
38kg/m
43kg/m
43kg/m
Power Source

3 phase 380V AC 50Hz OR Customer’s requirement
